Overview

Scality builds software-defined storage that runs on standard servers instead of purpose-built arrays. RING spreads objects across a pool of commodity nodes and presents them through file and S3-compatible object interfaces, and ARTESCA is the smaller, container-native object platform aimed at edge and backup targets. Because the storage is software on servers you already own, the estate question splits in two: what capacity and tenancy the platform reports, and which physical machines are carrying it.

The ReadyWorks connector is a JSON REST client for the Scality management interface, running on the json_rest_api.php driver. It takes an API domain, a username and password, and a server-side working path used while a response is parsed, and it authenticates with a Base64-encoded HTTP Basic header. This is the most minimal connection form in the storage set: four fields, with no Single Authentication control and no connection-wide Additional Job Fields list.

For ReadyWorks that second half of the question is the interesting one. Capacity and bucket records describe the service; the underlying nodes are servers with serial numbers, warranties and refresh dates that belong in the same estate view as the rest of the hardware. Pulling both sides in lets you see that a storage service depends on a specific set of machines, plan node replacement without losing the data protection the RING provides, and hold tenants and consumed capacity against the business owners who are being charged for them.

The connector is registered as bidirectional. Inbound jobs pull into staging, and the outbound side posts a record from ReadyWorks to an endpoint you nominate, mapping status, message and record key from the reply. Neither direction ships with an endpoint configured.

NOTE: Because there is no Single Authentication control on this connection form, the authentication phase runs again on every pagination and enumeration loop. That is fixed behaviour for this connector and cannot be turned off from the connection.

Connector Properties

Property Value
Identifier SCALITY
Name Scality
Description Scality file and object storage
Job Types Both Inbound and Outbound
Order 370
Enabled Yes
Locked Yes
Block Update No
Single Authentication No
Windows Only No
Connector Version 2026-08-10
Hooks None
Additional Job Fields None

Authentication Methods

Scality offers a single authentication method, using a username and password sent as an HTTP Basic credential.

Method Identifier Base Method Script Order Enabled Config Fields
Basic Authorization: Username / Password SCALITY_7cdfe7753a SCALITY_7cdfe7753a json_rest_api.php 70 Yes 4

Method 1: Basic Authorization: Username / Password (SCALITY_7cdfe7753a)

Connect to a GET method API with a username / password

Joins the connection’s username and password, Base64-encodes them and sends them as an Authorization: Basic header. Use an account with read access to the management interface you are collecting from, and confirm which of the Scality management surfaces your deployment exposes, since RING and ARTESCA present different administrative interfaces on different addresses.

Connection Configuration Fields (4)

Order Label Type Required Default Max Len Tooltip
10 API Domain text Yes 255 Enter API domain of the Connection
10 Server Temporary Working Path text Yes storage/etl5 255 Enter path where temporary files are stored during data processing (exclude starting and ending backslash)
40 Username text No 1024 Tooltip for Username
50 Password password No 64000 Tooltip for Password

Authentication Configuration

Headers sent on the authentication call:

Header Value Base64
Content-Type: application/json Off
Authorization: Basic %user_name%:%user_pass% On

cURL options:

Option Authentication Call Data Calls
USERAGENT Mozilla/5.0 (Windows NT 6.1; Win64; x64; rv:47.0) Gecko/20100101 Firefox/47.0 Same
SSL_VERIFYHOST false Same
SSL_VERIFYPEER false Same
RETURNTRANSFER true Same
FOLLOWLOCATION true Same
FAILONERROR true Same

NOTE: Username and Password are both marked optional even though the Basic credential is assembled from them. A connection saved with either field blank will send a malformed credential rather than failing at save time.

Inbound Job Fields Enabled (44)

Inbound jobs expose the full REST field set, including three levels of enumeration and all five pagination modes.

Order Label Type Required Default Tooltip
10 Job Description text Yes Enter description of the Job
20 Job Schedule lookup Yes Daily Select frequency Job should run
30 Enabled radio Yes Yes Choose if Job is enabled
40 Use Unparsed Data radio No No Choose if you wish to parse the incoming data, or leave it in its raw format
50 Log Raw API Calls radio Yes No Choose if raw API calls are logged
70 Destination Table text Yes Enter name of the destination table
80 Data Identity text No Enter identity of the Job
120 Append New Data to Existing Tables radio No No Choose if new data will append to the existing destination table, or will create a new destination table
130 Fields to Index text No Enter fields to index
170 Method Type select Yes GET Select method type of the Job
190 API End Point text No Enter API end point of the Job
200 API Data Parameters fields_list No Enter API data parameters of the Job
210 Body Data Sending Method select Yes JSON Encoded Data Select method for sending the body data
220 Raw JSON Body Data textarea No Enter the raw JSON body to send. Do not use body selections in the API Parameters if this is used.
230 API Return Data Node text No Enter API return data node of the Job
250 Pagination Type select No None Select request paging type of the Job
270 API Pagination Node text No Enter API pagination node of the Job
280 Pagination Offset Start text No Enter request paging offset start of the Job
290 Pagination Limit text No Enter request pagination limit of the Job
300 Pagination Termination Node text No Enter request paging termination node and value of the Job
310 Maximum API Calls text No Enter maximum number of API calls for the Job to make
320 Enumeration 1 Type select No None Enter enumeration level 1 type
330 Enumeration 1 ETL Job lookup No Select ETL job for the enumeration values
340 Enumeration 1 Data Type data_type No Select the data type and fields for enumeration 1 values
350 Enumeration 1 Keys End Point text No Enter enumeration 1 keys end point of the Job
360 Enumeration 1 Node text No Enter enumeration 1 node of the Job
370 Enumeration 1 Fields fields_list No Enter enumeration 1 fields of the Job
380 Enumeration 2 Type select No None Enter enumeration level 2 type
390 Enumeration 2 ETL Job lookup No Select ETL job for the enumeration 2 values
400 Enumeration 2 Data Type data_type No Select the data type and fields for enumeration 2 values
410 Enumeration 2 Keys End Point text No Enter enumeration 2 keys end point of the Job
420 Enumeration 2 Node text No Enter enumeration 2 node of the Job
430 Enumeration 2 Fields fields_list No Enter enumeration 2 fields of the Job
440 Enumeration 3 Type select No None Enter enumeration level 3 type
450 Enumeration 3 ETL Job lookup No Select ETL job for the enumeration 3 values
460 Enumeration 3 Data Type data_type No Select the data type and fields for enumeration 3 values
470 Enumeration 3 Keys End Point text No Enter enumeration 3 keys end point of the Job
480 Enumeration 3 Node text No Enter enumeration 3 node of the Job
490 Enumeration 3 Fields fields_list No Enter enumeration 3 fields of the Job
500 Pause Enumeration text No Enter values for pausing enumeration every X calls for Y seconds
510 Kill Enumeration on Error radio No No Choose to stop the enumeration loop on an error or continue processing the loop
520 Additional Fields fields_list No Enter list of additional fields to add to staging data
550 Retry Pause text No Enter values for retrying a failed API connection. Retry X times, waiting Y seconds between each try, with an API timeout of Z seconds.
560 Order text Yes Enter order of the Job

NOTE: Several labels and tooltips in this form carry defects inherited from the shared ETL5 field templates: the Enumeration 1 Node label reads “Enumaration”, the Append New Data label reads “Exisiting”, and the help text on Enumeration 1 Keys End Point and Enumeration 3 Fields both refer to enumeration 2. The underlying fields behave as their labels say.

Outbound Job Fields Enabled (13)

Outbound jobs expose the REST posting field set, including the outbound field list, the return data mapping and an optional raw JSON body template.

Order Label Type Required Default Tooltip
10 Job Description text Yes Enter description of the Job
30 Enabled radio Yes Yes Choose if Job is enabled
50 Log Raw API Calls radio Yes No Choose if raw API calls are logged
170 Method Type select Yes GET Select method type of the Job
180 Data Sending Method select Yes JSON Encoded Data Select method for sending the outbound data
190 API End Point text No Enter API end point of the Job
200 API Data Parameters fields_list No Enter API data parameters of the Job
210 Body Data Sending Method select Yes JSON Encoded Data Select method for sending the body data
260 Return Data Fields List fields_list Yes Enter return data fields of the Job
530 Outbound Fields List fields_list Yes Enter outbound fields of the Job
540 Ignore Empty Outbound Fields radio No Yes Ignore, and do not include, any outbound fields that are empty and have no data
550 Raw JSON Outbound Template textarea No Enter the raw JSON outbound template to send. This will replace any automated structures defined in the outbound fields.
560 Order text Yes Enter order of the Job

Inbound Job Templates (1)

Scality ships one inbound template, and it is the generic REST skeleton rather than a RING or ARTESCA data pull.

# Job Description Destination Table API End Point Enabled What It Pulls
1 Rest GET API api_data Not set No An empty starting point for a GET request, with no API End Point, no return data node and no pagination, writing to a placeholder staging table called api_data. It provides an authenticated shell for jobs you build yourself.

Job Template Configuration

Settings

Setting Value
Order 10
Enabled No
Job Schedule Daily (15 1 * * *)
Destination Table api_data
Data Identity api_data
Allow Empty Table Yes
Append Files to Same Destination Table No
Append New Data to Existing Tables No
Use Unparsed Data No
Convert UUID-Keyed Objects to Rows No
Ignore XML Attributes No
Log Raw API Calls No
Method Type GET
Body Data Sending Method JSON Encoded Data

Outbound Job Templates (1)

One outbound template ships, and it is the matching generic REST skeleton.

# Job Description Method API End Point Enabled What It Does
1 Rest POST API POST Not set No An empty POST job. It sends a single required string field named record_key as a JSON body to an endpoint you supply, and reads status, message and data.record_key back out of the response.

Job Template Configuration

Settings

Setting Value
Order 10
Enabled No
Log Raw API Calls No
Method Type POST
Body Data Sending Method JSON Encoded Data
Data Sending Method JSON Encoded Data
Ignore Empty Outbound Fields Yes

Job Parameters and Enumeration

Rest POST API

Outbound fields list:

Label Name Type Required Pattern
Record Key record_key String on

Return data fields:

Label Name
Return Status status
Return Message message
Record Key data.record_key
